TX20 Straightening Machine
2016-6-16 13:10:32
Applicable Industry£ºMainly used in all kinds of section steels, for example, angle steel, channel steel, I-steel, H section, square steel, round steel, steel pipe and axis class to straight or bend, widely used in electric, bridge, construction machine, iron tower, sheet metal and maintain etc. it also can be used for horizontal pressure machine.
Product Feature
¡öThe fuselage of section straightening machine is the C steel welding structure, has the rigidity well, the supporting capacity big, ease of operation merits and so on.
¡öTransmission styles include hydraulic transmission and engine transmission, users can choose them freely.
¡öOperation location divided into the single location and the double location, each location all has the alone disposition seal width adjusting device and in the table bracket installment, the operation is more flexible, accurate and safe.
¡öMay attach the auxiliary unit according to the customers¡¯ requirements, for example, the roller conveyor.
SPECIFICATIONS
|
ÐͺŠ|
TXZ20 | |
|
Max size of work piece(mm) |
Angles |
40§ç40§ç3¡«200§ç200§ç20 |
|
Round steel |
Below 150 | |
|
Channel steel |
Below 260 | |
|
Band steel |
Below 260 | |
|
Square steel |
Below 150 | |
|
Maximum straightening force (kN) |
1000 | |
|
Working stroke(mm) |
20 | |
|
Times of stroke(min-1) |
25 | |
|
Max close width (mm) |
220 | |
|
Adjustable stroke(mm) |
100 | |
|
Slider center to machine(mm) |
135 | |
|
Center distance of slider max bearing (mm) |
800 | |
|
Center height of slider (mm) |
200 | |
|
Quantity of station |
1 | |
|
Motor power (kW) |
7.5 | |
|
Overall dimension L¡Á W¡ÁH (mm) |
2450x1680x1440 | |
|
Weight of machine (kg) |
¡Ö3000 | |
